Parts list
| Pos. | Part No. | Description | Qty | Price | Stock | Buy |
|---|---|---|---|---|---|---|
| 001 | 911133-5 | PAN HEAD SCREW M4X18 | 2 | €0.56 | 1-4 weeks to ship | |
| 002 | 911158-9 | PAN HEAD SCREW M4X30 | 1 | €0.56 | 1-4 weeks to ship | |
| 003 | 411185-1 | MOTOR REAR COVER | 1 | €10.71 | 1-4 weeks to ship | |
| 004 | 812004-8 | SCALE LABEL | 1 | €2.09 | 1-4 weeks to ship | |
| 005 | 271226-3 | KNOB 50 | 1 | €8.35 | 1-4 weeks to ship | |
| 006 | 941251-5 | FLAT WASHER 10 | 1 | €0.56 | 1-4 weeks to ship | |
| 007 | 156312-0 | MAIN FRAME | 1 | €82.52 | 1-4 weeks to ship | |
| 008 | 953106-2 | RIVET 0-5 | 4 | €0.56 | 1-4 weeks to ship | |
| 009 | 811797-4 | NAME PLATE 1125 | 1 | €2.92 | 1-4 weeks to ship | |
| 013 | 682504-0 | CORD GUARD 10-85 | 1 | €1.67 | 1-4 weeks to ship | |
| 682504-0 | CORD GUARD 10-85 | 1 | €1.67 | 1-4 weeks to ship | ||
| 017 | 911153-9 | PAN HEAD SCREW M4X28 | 2 | €0.56 | 1-4 weeks to ship | |
| 018 | 911163-6 | PAN HEAD SCREW M4X35 | 1 | €0.56 | 1-4 weeks to ship | |
| 019 | 911158-9 | PAN HEAD SCREW M4X30 | 1 | €0.56 | 1-4 weeks to ship | |
| 020 | 911114-9 | PAN HEAD SCREW M4X10 | 2 | €0.56 | 1-4 weeks to ship | |
| 022 | 643601-7 | BRUSH HOLDER 6-10 | 2 | €1.11 | 1-4 weeks to ship | |
| 023 | 951131-7 | SPRING PIN 4-40 | 1 | €0.56 | 1-4 weeks to ship | |
| 024 | 342391-6 | DRUM COVER | 1 | €4.45 | 1-4 weeks to ship | |
| 025 | 911116-5 | PAN HEAD SCREW M4X12 | 3 | €0.56 | 1-4 weeks to ship | |
| 026 | 312644-7 | DRUM HOUSING | 1 | €16.70 | 1-4 weeks to ship | |
| 027 | 924206-5 | WING BOLT M5X10 | 1 | €0.56 | 1-4 weeks to ship | |
| 924206-5 | WING BOLT M5X10 | 1 | €0.56 | 1-4 weeks to ship | ||
| 028 | 942101-7 | SPRING WASHER 5 | 1 | €0.56 | 1-4 weeks to ship | |
| 942101-7 | SPRING WASHER 5 | 1 | €0.56 | 1-4 weeks to ship | ||
| 029 | 941101-4 | FLAT WASHER 5 | 1 | €0.56 | 1-4 weeks to ship | |
| 030 | 342390-8 | DEPTH GUIDE | 1 | €2.78 | 1-4 weeks to ship | |
| 031 | 251804-5 | SCREW M6X13 | 1 | €1.11 | 1-4 weeks to ship | |
| 033 | 421107-3 | RUBBER PACKING | 1 | €4.45 | 1-4 weeks to ship | |
| 034 | 312653-6 | FRONT BASE | 1 | €63.87 | 1-4 weeks to ship | |
| 035 | 312642-1 | BASE | 1 | €44.25 | 1-4 weeks to ship | |
| 036 | 911226-8 | PAN HEAD SCREW M5X18 | 4 | €0.56 | 1-4 weeks to ship | |
| 037 | 251609-3 | HEX. FLANGE HEAD BOLT M6X17 | 6 | €0.56 | 1-4 weeks to ship | |
| 039 | 251246-3 | + PAN HEAD SCREW M4X5 | 4 | €0.56 | 1-4 weeks to ship | |
| 041 | 323487-2 | DRUM REAR SHAFT | 1 | €11.13 | 1-4 weeks to ship | |
| 042 | 253171-4 | FLAT WASHER 10 | 1 | €0.56 | 1-4 weeks to ship | |
| 043 | 211061-7 | BALL BEARING 6000LLB | 1 | €2.78 | 1-4 weeks to ship | |
| 044 | 961006-2 | RETAINING RING S-10 | 1 | €0.56 | 1-4 weeks to ship | |
| 045 | DRUM | 1 | Not available in store | |||
| 046 | 257013-4 | RING 12 | 1 | €2.92 | 1-4 weeks to ship | |
| 049 | 211031-6 | BALL BEARING 608LLB | 1 | €1.67 | 1-4 weeks to ship | |
| 050 | 681613-2 | INSULATION WASHER | 1 | €0.56 | 1-4 weeks to ship | |
| 052 | 241044-3 | FAN 68 | 1 | €5.01 | 1-4 weeks to ship | |
| 053 | 211066-7 | BALL BEARING 6200LLB | 1 | €6.12 | 1-4 weeks to ship | |
| 054 | 263002-9 | RUBBER PIN 4 | 1 | €0.56 | 1-4 weeks to ship | |
| 055 | PAN HEAD SCREW M4X28 | 6 | Not available in store | |||
| 056 | 222050-7 | V-PULLEY 4-24L | 1 | €8.35 | 1-4 weeks to ship | |
| 057 | 411208-5 | BAFFLE PLATE | 1 | €4.45 | 1-4 weeks to ship | |
| 058 | 263002-9 | RUBBER PIN 4 | 1 | €0.56 | 1-4 weeks to ship | |
| 059 | 911101-8 | PAN HEAD SCREW M4X6 | 2 | €0.56 | 1-4 weeks to ship | |
| 060 | 342389-3 | BAFFLE PLATE | 1 | €2.78 | 1-4 weeks to ship | |
| 061 | 911111-5 | PAN HEAD SCREW M4X10 WITH | 2 | €0.56 | 1-4 weeks to ship | |
| 062 | 341265-8 | CHIP DEFLECTOR | 1 | €2.92 | 1-4 weeks to ship | |
| 063 | 211106-1 | BALL BEARING 6201LLB | 1 | €5.57 | 1-4 weeks to ship | |
| 064 | 263005-3 | RUBBER PIN 6 | 1 | €0.56 | 1-4 weeks to ship | |
| 065 | BRACKET COMPLETE | 1 | Not available in store | |||
| 066 | 222051-5 | V-PULLEY 4-44 | 1 | €18.09 | 1-4 weeks to ship | |
| 068 | 411186-9 | BELT COVER | 1 | €6.40 | 1-4 weeks to ship | |
| 069 | 911153-9 | PAN HEAD SCREW M4X28 | 2 | €0.56 | 1-4 weeks to ship | |
| 400 | 924216-2 | WING BOLT M5X15 | 2 | €0.56 | 1-4 weeks to ship | |
| 401 | 942101-7 | SPRING WASHER 5 | 2 | €0.56 | 1-4 weeks to ship | |
| 942101-7 | SPRING WASHER 5 | 2 | €0.56 | 1-4 weeks to ship | ||
| 402 | 941101-4 | FLAT WASHER 5 | 2 | €0.56 | 1-4 weeks to ship | |
| 403 | 342392-4 | BEVEL GUIDE | 1 | €15.03 | 1-4 weeks to ship | |
| 404 | 161037-3 | GUIDE RULE | 1 | €58.16 | 1-4 weeks to ship | |
| 405 | 411086-3 | GAUGE PLATE | 1 | €2.78 | 1-4 weeks to ship | |
| 406 | 911228-4 | PAN HEAD SCREW M5X18 | 2 | €0.56 | 1-4 weeks to ship | |
| 407 | BLADE GAUGE ASS'Y | 1 | Not available in store | |||
| 409 | SOCKET WRENCH 9 | 1 | Not available in store | |||
| 411 | 934301-3 | WING NUT M6 | 2 | €0.56 | 1-4 weeks to ship | |
| 934301-3 | WING NUT M6 | 2 | €0.56 | 1-4 weeks to ship | ||
| 413 | SHARPENING HOLDER ASS'Y | 1 | Not available in store | |||
| 414 | 251920-3 | CAP SQUARE NECK BOLT M6X30 | 2 | €2.09 | 1-4 weeks to ship | |
