2708
2708
Parts list
| Pos. | Part No. | Description | Qty | Price | Stock | Buy |
|---|---|---|---|---|---|---|
| 001 | 652012-5 | PAN HEAD SCREW M4X8 | 1 | €0.83 | 1-4 weeks to ship | |
| 652012-5 | PAN HEAD SCREW M4X8 | 1 | €0.83 | 1-4 weeks to ship | ||
| 003 | 211068-3 | BALL BEARING 6200LB | 1 | €8.07 | 1-4 weeks to ship | |
| 211068-3 | BALL BEARING 6200LB | 1 | €8.07 | 1-4 weeks to ship | ||
| 005 | POINTER B | 1 | Not available in store | |||
| POINTER B | 1 | Not available in store | ||||
| 006 | 911263-2 | PAN HEAD SCREW M5X40 | 4 | €0.56 | 1-4 weeks to ship | |
| 911263-2 | PAN HEAD SCREW M5X40 | 4 | €0.56 | 1-4 weeks to ship | ||
| 911263-2 | PAN HEAD SCREW M5X40 | 4 | €0.56 | 1-4 weeks to ship | ||
| 911263-2 | PAN HEAD SCREW M5X40 | 4 | €0.56 | 1-4 weeks to ship | ||
| 012 | 321478-7 | SCREW BAR M12 | 1 | €17.53 | 1-4 weeks to ship | |
| 321478-7 | SCREW BAR M12 | 1 | €17.53 | 1-4 weeks to ship | ||
| 013 | 411448-5 | BAFFLE PLATE | 1 | €7.51 | 1-4 weeks to ship | |
| 411448-5 | BAFFLE PLATE | 1 | €7.51 | 1-4 weeks to ship | ||
| 014 | SPRING PIN 5-16 | 1 | Not available in store | |||
| SPRING PIN 5-16 | 1 | Not available in store | ||||
| 016 | 271254-8 | KNOB 45 | 1 | €19.76 | 1-4 weeks to ship | |
| 271254-8 | KNOB 45 | 1 | €19.76 | 1-4 weeks to ship | ||
| 018 | 213202-1 | DUST SEAL 15 | 1 | €0.83 | 1-4 weeks to ship | |
| 213202-1 | DUST SEAL 15 | 1 | €0.83 | 1-4 weeks to ship | ||
| 019 | 211206-7 | BALL BEARING 6202LLB | 1 | €8.35 | 1-4 weeks to ship | |
| 211206-7 | BALL BEARING 6202LLB | 1 | €8.35 | 1-4 weeks to ship | ||
| 020 | 315431-3 | GEAR HOUSING | 1 | €45.78 | 1-4 weeks to ship | |
| 315431-3 | GEAR HOUSING | 1 | €45.78 | 1-4 weeks to ship | ||
| 021 | 911241-2 | PAN HEAD SCREW M5X25 | 4 | €0.56 | 1-4 weeks to ship | |
| 911241-2 | PAN HEAD SCREW M5X25 | 4 | €0.56 | 1-4 weeks to ship | ||
| 023 | 341927-8 | PRESSURE PLATE | 1 | €2.78 | 1-4 weeks to ship | |
| 341927-8 | PRESSURE PLATE | 1 | €2.78 | 1-4 weeks to ship | ||
| 024 | 341928-6 | ADJUST WASHER | 4 | €2.78 | 1-4 weeks to ship | |
| 341928-6 | ADJUST WASHER | 4 | €2.78 | 1-4 weeks to ship | ||
| 026 | 254013-5 | WOODRUFF KEY 5 | 1 | €2.09 | 1-4 weeks to ship | |
| 254013-5 | WOODRUFF KEY 5 | 1 | €2.09 | 1-4 weeks to ship | ||
| 027 | 931502-4 | HEX. NUT M10 | 1 | €0.56 | 1-4 weeks to ship | |
| 931502-4 | HEX. NUT M10 | 1 | €0.56 | 1-4 weeks to ship | ||
| 029 | 942251-8 | SPRING WASHER 10 | 1 | €0.56 | 1-4 weeks to ship | |
| 942251-8 | SPRING WASHER 10 | 1 | €0.56 | 1-4 weeks to ship | ||
| 034 | 168098-4 | FRAME | 1 | €127.04 | 1-4 weeks to ship | |
| 168098-4 | FRAME | 1 | €127.04 | 1-4 weeks to ship | ||
| 035 | 341870-1 | LINK | 1 | €8.49 | 1-4 weeks to ship | |
| 341870-1 | LINK | 1 | €8.49 | 1-4 weeks to ship | ||
| 036 | 231758-2 | TENSION SPRING 13 | 1 | €4.45 | 1-4 weeks to ship | |
| 231758-2 | TENSION SPRING 13 | 1 | €4.45 | 1-4 weeks to ship | ||
| 037 | 253813-0 | FLAT WASHER 12 | 1 | €0.56 | 1-4 weeks to ship | |
| 253813-0 | FLAT WASHER 12 | 1 | €0.56 | 1-4 weeks to ship | ||
| 038 | 265279-2 | HEX. BOLT M10 | 1 | €5.43 | 1-4 weeks to ship | |
| 265279-2 | HEX. BOLT M10 | 1 | €5.43 | 1-4 weeks to ship | ||
| 040 | 961060-6 | RETAINING RING S-20 | 1 | €0.56 | 1-4 weeks to ship | |
| 961060-6 | RETAINING RING S-20 | 1 | €0.56 | 1-4 weeks to ship | ||
| 041 | 212066-0 | NEEDLE BEARING 1015 | 1 | €17.53 | 1-4 weeks to ship | |
| 212066-0 | NEEDLE BEARING 1015 | 1 | €17.53 | 1-4 weeks to ship | ||
| 045 | SPRING PIN 5-16 | 1 | Not available in store | |||
| SPRING PIN 5-16 | 1 | Not available in store | ||||
| 046 | 257588-3 | SLEEVE 9 | 1 | €4.45 | 1-4 weeks to ship | |
| 257588-3 | SLEEVE 9 | 1 | €4.45 | 1-4 weeks to ship | ||
| 047 | 253733-8 | FLAT WASHER 9 | 1 | €0.56 | 1-4 weeks to ship | |
| 253733-8 | FLAT WASHER 9 | 1 | €0.56 | 1-4 weeks to ship | ||
| 049 | 253847-3 | FLAT WASHER 40 | 1 | €4.45 | 1-4 weeks to ship | |
| 253847-3 | FLAT WASHER 40 | 1 | €4.45 | 1-4 weeks to ship | ||
| 050 | 211306-3 | BALL BEARING 6204LLB | 1 | €13.92 | 1-4 weeks to ship | |
| 211306-3 | BALL BEARING 6204LLB | 1 | €13.92 | 1-4 weeks to ship | ||
| 051 | 321477-9 | SPINDLE | 1 | €34.51 | 1-4 weeks to ship | |
| 321477-9 | SPINDLE | 1 | €34.51 | 1-4 weeks to ship | ||
| 055 | 341886-6 | POINTER A | 1 | €4.45 | 1-4 weeks to ship | |
| 341886-6 | POINTER A | 1 | €4.45 | 1-4 weeks to ship | ||
| 056 | 911204-8 | PAN HEAD SCREW M5X8 | 2 | €2.09 | 1-4 weeks to ship | |
| 911204-8 | PAN HEAD SCREW M5X8 | 2 | €2.09 | 1-4 weeks to ship | ||
| 057 | BLADE COVER | 1 | Not available in store | |||
| BLADE COVER | 1 | Not available in store | ||||
| 058 | INNER FLANGE 55 | 1 | Not available in store | |||
| INNER FLANGE 55 | 1 | Not available in store | ||||
| 059 | OUTER FLANGE 55 | 1 | Not available in store | |||
| OUTER FLANGE 55 | 1 | Not available in store | ||||
| 060 | 931602-0 | HEX. NUT M12 | 1 | €0.56 | 1-4 weeks to ship | |
| 931602-0 | HEX. NUT M12 | 1 | €0.56 | 1-4 weeks to ship | ||
| 065 | 911316-7 | PAN HEAD SCREW M6X14 | 2 | €0.83 | 1-4 weeks to ship | |
| 911316-7 | PAN HEAD SCREW M6X14 | 2 | €0.83 | 1-4 weeks to ship | ||
| 066 | 911316-7 | PAN HEAD SCREW M6X14 | 4 | €0.83 | 1-4 weeks to ship | |
| 911316-7 | PAN HEAD SCREW M6X14 | 4 | €0.83 | 1-4 weeks to ship | ||
| 070 | 931302-2 | HEX. NUT M6 | 2 | €0.56 | 1-4 weeks to ship | |
| 931302-2 | HEX. NUT M6 | 2 | €0.56 | 1-4 weeks to ship | ||
| 071 | CAP 20 | 4 | Not available in store | |||
| CAP 20 | 4 | Not available in store | ||||
| 072 | 911344-2 | PAN HEAD SCREW M6X25 | 6 | €0.56 | 1-4 weeks to ship | |
| 911344-2 | PAN HEAD SCREW M6X25 | 6 | €0.56 | 1-4 weeks to ship | ||
| 079 | 411447-7 | LOCK OFF SWITCH BUTTON | 1 | €1.39 | 1-4 weeks to ship | |
| 411447-7 | LOCK OFF SWITCH BUTTON | 1 | €1.39 | 1-4 weeks to ship | ||
| 083 | 854783-2 | NAME PLATE 2708 | 1 | €2.92 | 1-4 weeks to ship | |
| 854783-2 | NAME PLATE 2708 | 1 | €2.92 | 1-4 weeks to ship | ||
| 089 | 312749-3 | BEARING BOX | 1 | €12.52 | 1-4 weeks to ship | |
| 312749-3 | BEARING BOX | 1 | €12.52 | 1-4 weeks to ship | ||
| 090 | 911221-8 | PAN HEAD SCREW M5X16 | 2 | €0.56 | 1-4 weeks to ship | |
| 911221-8 | PAN HEAD SCREW M5X16 | 2 | €0.56 | 1-4 weeks to ship | ||
| 091 | 231378-2 | COMPRESSION SPRING 24 | 1 | €2.78 | 1-4 weeks to ship | |
| 231378-2 | COMPRESSION SPRING 24 | 1 | €2.78 | 1-4 weeks to ship | ||
| 092 | 342797-8 | RETAINER | 2 | €2.78 | 1-4 weeks to ship | |
| 342797-8 | RETAINER | 2 | €2.78 | 1-4 weeks to ship | ||
| 093 | 911252-7 | PAN HEAD SCREW M5X30 | 2 | €0.56 | 1-4 weeks to ship | |
| 911252-7 | PAN HEAD SCREW M5X30 | 2 | €0.56 | 1-4 weeks to ship | ||
| 094 | 267015-2 | FLAT WASHER 9 | 1 | €2.09 | 1-4 weeks to ship | |
| 267015-2 | FLAT WASHER 9 | 1 | €2.09 | 1-4 weeks to ship | ||
| 400 | 271401-1 | KNOB 32 | 1 | €0.97 | 1-4 weeks to ship | |
| 271401-1 | KNOB 32 | 1 | €0.97 | 1-4 weeks to ship | ||
| 401 | 253047-5 | FLAT WASHER 6 | 1 | €0.56 | 1-4 weeks to ship | |
| 253047-5 | FLAT WASHER 6 | 1 | €0.56 | 1-4 weeks to ship | ||
| 407 | 265809-9 | CAP SQUARE NEC BOLT M8X500 | 1 | €12.52 | 1-4 weeks to ship | |
| 265809-9 | CAP SQUARE NEC BOLT M8X500 | 1 | €12.52 | 1-4 weeks to ship | ||
| 410 | 341888-2 | RULE UNDER PLATE | 1 | €6.68 | 1-4 weeks to ship | |
| 341888-2 | RULE UNDER PLATE | 1 | €6.68 | 1-4 weeks to ship | ||
| 412 | 164620-5 | RULER | 1 | €66.65 | 1-4 weeks to ship | |
| 164620-5 | RULER | 1 | €66.65 | 1-4 weeks to ship | ||
| 414 | 911214-5 | PAN HEAD SCREW M5X12 | 1 | €0.83 | 1-4 weeks to ship | |
| 911214-5 | PAN HEAD SCREW M5X12 | 1 | €0.83 | 1-4 weeks to ship | ||
| 415 | 816099-3 | INDICATION PLATE | 1 | €2.92 | 1-4 weeks to ship | |
| 816099-3 | INDICATION PLATE | 1 | €2.92 | 1-4 weeks to ship | ||
| 416 | 273465-1 | GRIP 28 | 1 | €4.45 | 1-4 weeks to ship | |
| 273465-1 | GRIP 28 | 1 | €4.45 | 1-4 weeks to ship | ||
| 424 | HEX. WRENCH 5 | 1 | Not available in store | |||
| HEX. WRENCH 5 | 1 | Not available in store | ||||
| 425 | 411447-7 | LOCK OFF SWITCH BUTTON | 2 | €1.39 | 1-4 weeks to ship | |
| 411447-7 | LOCK OFF SWITCH BUTTON | 2 | €1.39 | 1-4 weeks to ship | ||
| 426 | 342690-6 | SPACER | 3 | €2.78 | 1-4 weeks to ship | |
| 342690-6 | SPACER | 3 | €2.78 | 1-4 weeks to ship | ||
