DUH604S
DUH604S
Parts list
| Pos. | Part No. | Description | Qty | Price | Stock | Buy |
|---|---|---|---|---|---|---|
| 001 | GRIP SET | 1 | Not available in store | |||
| GRIP SET | 1 | Not available in store | ||||
| 003 | 233621-5 | TORSION SPRING 9 | 1 | €0.14 | 1-4 weeks to ship | |
| 233621-5 | TORSION SPRING 9 | 1 | €0.14 | 1-4 weeks to ship | ||
| 004 | SWITCH LEVER R | 1 | Not available in store | |||
| SWITCH LEVER R | 1 | Not available in store | ||||
| 005 | 233621-5 | TORSION SPRING 9 | 1 | €0.14 | 1-4 weeks to ship | |
| 233621-5 | TORSION SPRING 9 | 1 | €0.14 | 1-4 weeks to ship | ||
| 006 | 651083-9 | SWITCH C3XA-1PSPM | 1 | €18.09 | 1-4 weeks to ship | |
| 651083-9 | SWITCH C3XA-1PSPM | 1 | €18.09 | 1-4 weeks to ship | ||
| 651083-9 | SWITCH C3XA-1PSPM | 1 | €18.09 | 1-4 weeks to ship | ||
| 651083-9 | SWITCH C3XA-1PSPM | 1 | €18.09 | 1-4 weeks to ship | ||
| 007 | SUB CONTROLLER COMPLETE | 1 | Not available in store | |||
| SUB CONTROLLER COMPLETE | 1 | Not available in store | ||||
| 008 | GRIP SET | 1 | Not available in store | |||
| GRIP SET | 1 | Not available in store | ||||
| 009 | 266326-2 | TAPPING SCREW 4X18 | 4 | €0.56 | 1-4 weeks to ship | |
| 266326-2 | TAPPING SCREW 4X18 | 4 | €0.56 | 1-4 weeks to ship | ||
| 010 | 911253-5 | PAN HEAD SCREW M5X30 | 1 | €0.56 | 1-4 weeks to ship | |
| 911253-5 | PAN HEAD SCREW M5X30 | 1 | €0.56 | 1-4 weeks to ship | ||
| 011 | GRIP JOINT COVER | 1 | Not available in store | |||
| GRIP JOINT COVER | 1 | Not available in store | ||||
| 012 | GRIP JOINT | 1 | Not available in store | |||
| GRIP JOINT | 1 | Not available in store | ||||
| 013 | 266326-2 | TAPPING SCREW 4X18 | 8 | €0.56 | 1-4 weeks to ship | |
| 266326-2 | TAPPING SCREW 4X18 | 8 | €0.56 | 1-4 weeks to ship | ||
| 014 | HOUSING SET | 1 | Not available in store | |||
| HOUSING SET | 1 | Not available in store | ||||
| 015 | HOUSING SET | 1 | Not available in store | |||
| HOUSING SET | 1 | Not available in store | ||||
| 016 | 266326-2 | TAPPING SCREW 4X18 | 4 | €0.56 | 1-4 weeks to ship | |
| 266326-2 | TAPPING SCREW 4X18 | 4 | €0.56 | 1-4 weeks to ship | ||
| 017 | DUH604S NAME PLATE | 1 | Not available in store | |||
| DUH604S NAME PLATE | 1 | Not available in store | ||||
| 018 | DUH604S SERIAL NO. LABEL | 1 | Not available in store | |||
| DUH604S SERIAL NO. LABEL | 1 | Not available in store | ||||
| 019 | 643874-2 | TERMINAL | 1 | €3.90 | 1-4 weeks to ship | |
| 643874-2 | TERMINAL | 1 | €3.90 | 1-4 weeks to ship | ||
| 643874-2 | TERMINAL | 1 | €3.90 | 1-4 weeks to ship | ||
| 643874-2 | TERMINAL | 1 | €3.90 | 1-4 weeks to ship | ||
| 020 | 422261-6 | RUBBER SLEEVE | 1 | €1.95 | 1-4 weeks to ship | |
| 422261-6 | RUBBER SLEEVE | 1 | €1.95 | 1-4 weeks to ship | ||
| 021 | 266490-9 | TAPPING SCREW PT 2X6 | 3 | €0.14 | 1-4 weeks to ship | |
| 266490-9 | TAPPING SCREW PT 2X6 | 3 | €0.14 | 1-4 weeks to ship | ||
| 022 | 629352-6 | STATOR | 1 | €25.74 | 1-4 weeks to ship | |
| 629352-6 | STATOR | 1 | €25.74 | 1-4 weeks to ship | ||
| 023 | 652069-6 | FLAT HEAD SCREW M3X6 | 3 | €0.14 | 1-4 weeks to ship | |
| 652069-6 | FLAT HEAD SCREW M3X6 | 3 | €0.14 | 1-4 weeks to ship | ||
| 024 | 211157-4 | BALL BEARING 695ZZ | 1 | €1.39 | 1-4 weeks to ship | |
| 211157-4 | BALL BEARING 695ZZ | 1 | €1.39 | 1-4 weeks to ship | ||
| 025 | ROTOR ASSY | 1 | Not available in store | |||
| ROTOR ASSY | 1 | Not available in store | ||||
| 026 | 210005-4 | BALL BEARING 608DDW | 1 | €2.78 | 1-4 weeks to ship | |
| 210005-4 | BALL BEARING 608DDW | 1 | €2.78 | 1-4 weeks to ship | ||
| 027 | 911128-8 | P.H.SCREW M4X16 WITH WR | 4 | €0.56 | 1-4 weeks to ship | |
| 911128-8 | P.H.SCREW M4X16 WITH WR | 4 | €0.56 | 1-4 weeks to ship | ||
| 911128-8 | P.H.SCREW M4X16 WITH WR | 4 | €0.56 | 1-4 weeks to ship | ||
| 911128-8 | P.H.SCREW M4X16 WITH WR | 4 | €0.56 | 1-4 weeks to ship | ||
| 030 | 266326-2 | TAPPING SCREW 4X18 | 4 | €0.56 | 1-4 weeks to ship | |
| 266326-2 | TAPPING SCREW 4X18 | 4 | €0.56 | 1-4 weeks to ship | ||
| 031 | 266326-2 | TAPPING SCREW 4X18 | 4 | €0.56 | 1-4 weeks to ship | |
| 266326-2 | TAPPING SCREW 4X18 | 4 | €0.56 | 1-4 weeks to ship | ||
| 032 | 266326-2 | TAPPING SCREW 4X18 | 6 | €0.56 | 1-4 weeks to ship | |
| 266326-2 | TAPPING SCREW 4X18 | 6 | €0.56 | 1-4 weeks to ship | ||
| 034 | 651083-9 | SWITCH C3XA-1PSPM | 1 | €18.09 | 1-4 weeks to ship | |
| 651083-9 | SWITCH C3XA-1PSPM | 1 | €18.09 | 1-4 weeks to ship | ||
| 651083-9 | SWITCH C3XA-1PSPM | 1 | €18.09 | 1-4 weeks to ship | ||
| 651083-9 | SWITCH C3XA-1PSPM | 1 | €18.09 | 1-4 weeks to ship | ||
| 035 | SWITCH LEVER F | 1 | Not available in store | |||
| SWITCH LEVER F | 1 | Not available in store | ||||
| 036 | 233621-5 | TORSION SPRING 9 | 1 | €0.14 | 1-4 weeks to ship | |
| 233621-5 | TORSION SPRING 9 | 1 | €0.14 | 1-4 weeks to ship | ||
| 039 | 253416-0 | DISH WASHER 5 | 1 | €0.97 | 1-4 weeks to ship | |
| 253416-0 | DISH WASHER 5 | 1 | €0.97 | 1-4 weeks to ship | ||
| 040 | 422260-8 | RUBBER SLEEVE 8 | 1 | €2.09 | 1-4 weeks to ship | |
| 422260-8 | RUBBER SLEEVE 8 | 1 | €2.09 | 1-4 weeks to ship | ||
| 041 | 422260-8 | RUBBER SLEEVE 8 | 1 | €2.09 | 1-4 weeks to ship | |
| 422260-8 | RUBBER SLEEVE 8 | 1 | €2.09 | 1-4 weeks to ship | ||
| 042 | 257678-2 | SLEEVE 6 | 1 | €1.53 | 1-4 weeks to ship | |
| 257678-2 | SLEEVE 6 | 1 | €1.53 | 1-4 weeks to ship | ||
| 043 | 922228-9 | H.S.H.BOLT M5X18 WITH WR | 1 | €0.56 | 1-4 weeks to ship | |
| 922228-9 | H.S.H.BOLT M5X18 WITH WR | 1 | €0.56 | 1-4 weeks to ship | ||
| 044 | 253416-0 | DISH WASHER 5 | 1 | €0.97 | 1-4 weeks to ship | |
| 253416-0 | DISH WASHER 5 | 1 | €0.97 | 1-4 weeks to ship | ||
| 045 | 422260-8 | RUBBER SLEEVE 8 | 1 | €2.09 | 1-4 weeks to ship | |
| 422260-8 | RUBBER SLEEVE 8 | 1 | €2.09 | 1-4 weeks to ship | ||
| 046 | 422260-8 | RUBBER SLEEVE 8 | 1 | €2.09 | 1-4 weeks to ship | |
| 422260-8 | RUBBER SLEEVE 8 | 1 | €2.09 | 1-4 weeks to ship | ||
| 047 | CONNECTOR | 1 | Not available in store | |||
| CONNECTOR | 1 | Not available in store | ||||
| 048 | LOWER GUARD | 1 | Not available in store | |||
| LOWER GUARD | 1 | Not available in store | ||||
| 049 | 266326-2 | TAPPING SCREW 4X18 | 2 | €0.56 | 1-4 weeks to ship | |
| 266326-2 | TAPPING SCREW 4X18 | 2 | €0.56 | 1-4 weeks to ship | ||
| 050 | 213961-7 | O RING 22 | 1 | €0.56 | 1-4 weeks to ship | |
| 213961-7 | O RING 22 | 1 | €0.56 | 1-4 weeks to ship | ||
| 052 | 422259-3 | RUBBER SLEEVE 8 | 2 | €1.53 | 1-4 weeks to ship | |
| 422259-3 | RUBBER SLEEVE 8 | 2 | €1.53 | 1-4 weeks to ship | ||
| 055 | 347361-0 | FRICTION PLATE | 1 | €0.70 | 1-4 weeks to ship | |
| 347361-0 | FRICTION PLATE | 1 | €0.70 | 1-4 weeks to ship | ||
| 056 | CONNECTING ROD | 1 | Not available in store | |||
| CONNECTING ROD | 1 | Not available in store | ||||
| 057 | NEEDLE CAGE 315 | 1 | Not available in store | |||
| NEEDLE CAGE 315 | 1 | Not available in store | ||||
| 058 | GEAR COMPLETE | 1 | Not available in store | |||
| GEAR COMPLETE | 1 | Not available in store | ||||
| 059 | NEEDLE CAGE 315 | 1 | Not available in store | |||
| NEEDLE CAGE 315 | 1 | Not available in store | ||||
| 060 | CONNECTING ROD | 1 | Not available in store | |||
| CONNECTING ROD | 1 | Not available in store | ||||
| 061 | 347361-0 | FRICTION PLATE | 1 | €0.70 | 1-4 weeks to ship | |
| 347361-0 | FRICTION PLATE | 1 | €0.70 | 1-4 weeks to ship | ||
| 062 | BALL BEARING 626ZZ | 1 | Not available in store | |||
| BALL BEARING 626ZZ | 1 | Not available in store | ||||
| 063 | 443159-4 | SEAL | 1 | €5.57 | 1-4 weeks to ship | |
| 443159-4 | SEAL | 1 | €5.57 | 1-4 weeks to ship | ||
| 065 | H.S.BUTTON HEAD BOLT M6X4 | 1 | Not available in store | |||
| H.S.BUTTON HEAD BOLT M6X4 | 1 | Not available in store | ||||
| 066 | 922128-3 | HEX. SOCKET HEAD BOLT M4X16 | 6 | €0.56 | 1-4 weeks to ship | |
| 922128-3 | HEX. SOCKET HEAD BOLT M4X16 | 6 | €0.56 | 1-4 weeks to ship | ||
| 067 | SLEEVE 5 | 3 | Not available in store | |||
| SLEEVE 5 | 3 | Not available in store | ||||
| 071 | CHIP RECEIVER 600E SET | 1 | Not available in store | |||
| CHIP RECEIVER 600E SET | 1 | Not available in store | ||||
| 072 | 915211-3 | BINDING HEAD SCREW M5X12 | 4 | €0.56 | 1-4 weeks to ship | |
| 915211-3 | BINDING HEAD SCREW M5X12 | 4 | €0.56 | 1-4 weeks to ship | ||
